Product Features
At Rated Voltage: 1 HP
Brand: SmartlockPro
Type: Standard Duplex
Strap Material: Galvanized Steel
Grounding: Self Grounding
Warranty: 2-Year Limited
Color: Ivory
Trip Level: Class A, 5mA plus or minus 1mA
Grade: Residential/Commercial Specification Grade
Termination: Back & Side
Wire: 3
Feature: Self-Test
NEMA: 5-20R
Voltage: 125 VAC
Amperage: 20 A
Standards and Certifications: UL/CSA
Fed Spec WC-596: Yes
Pole: 2
Tamper Resistant: Yes
AC Horsepower Ratings
Dielectric Voltage: Withstands 1250VAC per UL 943 and CSA-C22.2 No. 144.1-06
Short Circuit Current Rating: 10KA
Temperature Rise: Max 30C after 100 cycles OL at 150 percent rated current
At Rated Voltage: 1 HP
Electrical Specifications
Operating Temperature: -35C to +66C
Dielectric Voltage: Withstands 1250VAC per UL 943 and CSA-C22.2 No. 144.1-06
Temperature Rise: Max 30C after 100 cycles OL at 150 percent rated current
Short Circuit Current Rating: 10KA
Environmental Specifications
Body Material: Polycarbonate
Clamps: Brass
Face Material: Thermoplastic
Grounding Screw: Plated Steel
Line Contacts: Brass Triple-Wipe
Notes: w/ Wallplate
Terminal Screws: Plated Steel
Yoke: Zinc-Plated Steel
Operating Temperature: -35C to +66C
Material Specifications
Product ID: Ratings are permanently marked on device
Terminal Accom.: 14-10 AWG
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
Body Material: Polycarbonate
Face Material: Thermoplastic
Terminal Screws: Plated Steel
Line Contacts: Brass Triple-Wipe
Yoke: Zinc-Plated Steel
Clamps: Brass
Grounding Screw: Plated Steel
Notes: w/ Wallplate
Mechanical Specifications
Amperage: 20 A
Body Material: Polycarbonate
Brand: SmartlockPro
Color: Ivory
Face Material: Thermoplastic
Feature: Self-Test
Fed Spec WC-596: Yes
Grade: Residential/Commercial Specification Grade
Grounding: Self Grounding
NEMA: 5-20R
Pole: 2
Standards and Certifications: UL/CSA
Strap Material: Galvanized Steel
Tamper Resistant: Yes
Termination: Back & Side
Trip Level: Class A, 5mA plus or minus 1mA
Type: Standard Duplex
Voltage: 125 VAC
Warranty: 2-Year Limited
Wire: 3
Product ID: Ratings are permanently marked on device
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
Terminal Accom.: 14-10 AWG
Standards and Certifications
ANSI: C-73
CSA-C22.2 No. 144.1-06: File LR-57811
CSA C22.2 No. 42: Yes
Fed Spec WC-596: Yes
MIL-SPEC: A-A-55459-SB
NOM: Yes
UL498: Yes
UL 943: File E48380
